Power Supply – 36V 600W
$ 93.92
- This Authentic and reliable Mean Well Power supply was designed to be used with 36V loads up to 600W. It has a DC fan forcing the heat out in order to keep the power supply within the working temperature range. The power supply also has a selectable AC input and Voltage Drop Compensation that can be easily adjusted by the use of the potentiometer. Specifications: Manufacturer: Mean Well Output Voltage: 36V Output Current: 16.6A Output Power: 597.6W Input Voltage: 90 ~ 132VAC / 180 ~ 264 VAC selected by switch Input Current: 12A/115VAC or 7.5A/230VAC Frequency Range: 47 ~ 63Hz Protection: Overload, Over Voltage, Over Temperature. Dimensions: 247x127x63.5mm Weight: 2.1kg Technical Drawing: Pro Tips: One of these power supplies is capable of driving 4x Stepper Motors up to 4 Amps each. Example: 4x Closed Loop Stepper Motor Driver – HSS57 paired with 4x Nema 23 Stepper Motor 2.45N.m – High Torque. Before turning it on, check the select the correct AC input range. Choosing the wrong input voltage will void the warranty, as well as damage your power supply. Datasheet: SE-600 SERIES – DATASHEET
